Status – displays the current feature datum association in the Name data field.Īdjust – opens a dialog to allow changes to current Status components. Names may also be edited directly in the data list.ĭatum Label – allows features in the name field to be tagged as a Datum to use with the Datum Reference Frame tool in the Report Manager.ĭatum Reference Frame – select and associate features to datums using drop-down menus for the Primary, Secondary, and Tertiary datums. Editing the name in the report does not affect the Measurement Data Tree. Name – by default, feature names originate in the Measure Data Tree to populate the Reports Data List. The GD&T Control Frame provides definition for the DRF Using Datum Reference Frames (DRFs) in Verisurf AUTOMATEĭatum Reference Frames can be quickly and easily set up for Features, Analysis objects, and Constructs using the General Tab in the Details Pane of the Automate Manager.
The controlling features are the datums, and the GD&T callouts tell which datums are to be used for referencing individual (or groups of) part features. Drawings or CAD model Product Manufacturing Information (PMI) designate Geometric Dimensioning and Tolerancing (GD&T) callouts or “control frames” which set the rules controlling from where part features are to be measured or referenced.
